Low-temperature Hydrogen Peroxide Plasma Sterilizer HTYD-60L

1.

Model and

weight

HTYD-60L

Approximately 233 kg (net weight)

2.

Cavity

structure and

material

Rectangular chamber for optimal space utilization; made of high-quality

stainless steel with thickness ≥3 mm, featuring excellent thermal

conductivity, extended service life, and enhanced deformation resistance.

3.

sterilizer inner

tank

Six-sided PTC silicone plate heating with independent temperature

control; uniform heating; dual protection for sterilization temperature to

ensure sterilization effectiveness and the safety of equipment and

personnel.

4.

sterilization

chamber door

★ Door Opening Method: Vertically automated lifting door, equipped

with anti-pinch safety system to protect users.

Door Obstruction Switch: When the obstruction switch is triggered, the

door automatically lowers to prevent injury or damage.

Foot-pedal Sensor: Allows hands-free door operation when both hands

are occupied.

★ Door Opening Method: Vertically automated lifting door, equipped

with anti-pinch safety system to protect users.

Door Obstruction Switch: When the obstruction switch is triggered, the

door automatically lowers to prevent injury or damage.

Foot-pedal Sensor: Allows hands-free door operation when both hands

are occupied.

5.

Sterilant

Cartridge-Type Dosing Method:

Uses a cartridge capsule system with 12 capsules in each cartridge. The

H₂O₂ dosing error is ≤1%, and the pH is ≤2.6.

The cartridge features an automatic capsule-counting memory function:

once installed, it automatically tracks the number of capsules used and

displays the remaining capsules and the number of full cycles available.

If the remaining amount is insufficient for the current sterilization cycle,

the system will automatically pop up a warning message and sound an

alarm to notify the operator.Pioneering and innovating

Practical,

Innovative

and

Operating principles: high quality, high reputation and excellent

Bottle-Type Dosing Method:

Uses a 58% hydrogen peroxide liquid bottle for dosing. When the liquid

level is insufficient for the next sterilization cycle, the system will issue

an alarm to remind the operator.

Note: Both machine versions are available for selection.

6.

sterilization

method

Optional hydrogen peroxide purification technology to increase

concentration to 95% ± 5%.

Hydrogen peroxide vaporization technology (90–100°C) generates

high-concentration H₂O₂ vapor within a closed system, ensuring efficient,

residue-free, and environmentally friendly sterilization.

7.

sterilization

rate

Sterilization speed: rapid sterilization ≤25min; standard sterilization

≤35min; enhanced sterilization ≤55min

8.

sterilization

temperature

50℃±3℃

9.

★ display

screen

Featuring a 7-inch touchscreen with 1024×600 resolution and 24-bit color

depth, the device is equipped with 256MB DDR3+ RAM and256MB

Flash storage. It complies with EN61000-6-2:2005 and

EN61000-6-4:2007 standards, and meets RoHS requirements for

lightning surge protection (±1kV), group impulse (±2kV), electrostatic

discharge (4kV), and air discharge (8kV). The system includes lightning

surge protection and allows power loss within 5 milliseconds.

10.

master

controller PLC

The new program design, display the working process parameters,

operation is convenient, simple and easy to understand, fully realize the

accuracy, standardization, safety and reliability of control;

11.

Print record

content

Printable records: program name, sterilization date, sterilizer batch, start

and end time of sterilization, pressure, temperature, stage time, curve

graph, and end status. The system also provides printed samples, physical

parameters, and photos of physical curve graphs.

12.

Sterilization

monitoring and

alarm

information

storage system

The system features a sterilization and alarm record traceability system,

with information directly displayed on the touchscreen for real-time

monitoring by relevant personnel. It can store complete sterilization

records for no fewer than 4,000 sterilization cycles.

13.

pressure

transmitter

High precision, high reliability, and stable output

14.

temperature

sensor

Major brand, stable, and low measurement error

15.

sterilizing filter Ultrafine sterile filtration, filtration level ≤0.22μm

16.

plasma power

Frequency: 19 kHz, Maximum power: 500W

17.

electromagnetic High corrosion-resistant materials, reliable operation and long service lifePioneering and innovating

Practical,

Innovative

and

Operating principles: high quality, high reputation and excellent

valve

18.

Cavity

temperature

heating power

1800W, no preheating required

19.

vacuum pump

The rotary vane vacuum pump, featuring ultra-high vacuum and H2O2

corrosion resistance, achieves a pumping rate of 16 cubic meters per hour

with operational noise below 65dB.

20.

vacuum pump

phase sequence

protector

A high-vacuum phase sequence protector is installed to prevent

equipment power supply phase sequence changes from causing vacuum

pump reversal and equipment failure.

21.

oil mist filter

The product features an exhaust oil mist filtration system that recovers oil

mist to prevent it from entering the air. Additionally, the system uses the

pump's suction to return the oil back into the pump for reuse, thereby

reducing fuel consumption.

22.

alarm system

The system features automatic detection and real-time

monitoring of the sterilization process. If any abnormalities

occur, the system automatically triggers an alarm and

displays the fault cause in Chinese.

23.

★Biological

indicator

incubator

The device is equipped with a bio-indicator incubator with independent

control, allowing independent bio-indicator testing even when the

equipment is not in operation. Parameters: 5-channel culture chamber,

accommodating up to five bio-indicators simultaneously. Temperature:

56℃±2℃, culture time ≤48 hours.

24.

test method

Biotracking of Bacillus thermophilus

25.

★

Maintenance

reminder

The device has a maintenance reminder feature. A pop-up will appear

when usage meets maintenance requirements, preventing reduced lifespan

due to inadequate maintenance.

26.

★Hydrogen

peroxide filter

The product features an exhaust hydrogen peroxide gas filtration system,

ensuring the surrounding air contains less than 0.6mg/m³ of hydrogen

peroxide.

27.

language

system

Supports five language systems: Chinese, English, Traditional Chinese,

Spanish, and Russian. Other language systems can be customized.

28.

Program

Settings

Multiple sterilization programs are configured based on the

characteristics of sterilized items, including surface sterilization for

medical devices (rapid sterilization), multi-device surface sterilization

(standard sterilization), and lumen sterilization (enhanced sterilization).

29.

★Traceability

system

Supports integration with hospital traceability systems and multiple

traceability protocols;

30.

All

consumables

are fully

stocked.

The manufacturer guarantees the unified supply of plasma-specific

indicator cards, tapes, packaging bags, sterilizers, biological indicators,

and biological incubators.Pioneering and innovating

Practical,

Innovative

and

Operating principles: high quality, high reputation and excellent

31.

Cavity

dimensions

(allowable

deviation ±5%)

620*350*280mm

32.

Outer box

dimensions

(allowable

deviation ±5%)

770*660*1400mm

33.

Pallet box

dimensions

(allowable

deviation ±5%)

790*680*1500mm

34.

Power supply

and power

220v

2.2KVA

35.

scope of

application

This method is suitable for sterilizing instruments that can withstand

vacuum negative pressure and hydrogen peroxide gas, as well as those

sensitive to high temperatures. However, it is not recommended for

powders, oily materials, or cotton textiles.

36.

sterilization

effect

Sterilization capability: 2m-long PTFE tube (inner diameter 1mm) and

500mm-long stainless steel tube (inner diameter 2mm) meet sterility

standards after sterilization, with third-party certification.
