Wholesale Factory suppy Economic Anesthesia Machine with built in Anesthesia Ventilator RE902-C7

Special Feature

High light LED display

Metal frame, with plastic spray technique, durable and lasting

Built-in Anesthesia Ventilator

Classical Flowmeter of 2 tubes

Integrated Circle Absorber, durable and practical

Working Mode: Semi~open, Semi~closed or Closed system

Gas Supply Pressure:

O₂: 0.27Mpa～0.55Mpa

N₂O: 0.27Mpa～0.55Mpa

Flow meter:

2 Tube: 1 x O₂ Tube, 1 x N₂O Tube,

O₂ tube: 0L/min ~10L/min.

N₂O tube: 0L/min ~10L/min.

O₂ and N₂O Linkage Device, keep oxygen concentration not lower than 25%

Oxygen flush: 25L/min~75L/min

Safety Function

a) When airway pressure reach 6 kPa, APL valve will automatically release gas

b) When airway pressure reach 6kPa, the Bellows will stop sending gas to patient

Monitoring parameters (Under Manual and Ventilation):

Tidal Volume

Minute Ventilation

I:E Ratio

Alarm (Audible and/or visual signal):

Airway Pressure high/low limit

Minute Ventilation high/low limit

Low O₂ Supply Pressure (when O₂ Supply Pressure is lower than 0.15Mpa, will arouse Audio Alarm)

N₂O automatic Cutoff Alarm

Anesthesia Ventilator

Respiration mode: IPPV, Manual

Tidal Volume: 50~1600ml

Respiratory frequency: 1~90bpm

I:E ratio:4:1~1:6

Anesthesia Vaporizer

The agent output is continuous, stable, and precise

Automatic compensation for Temperature, Flow and Pressure

Agent: Isoflurane, Enflurane for choice

Dimensions

Size: 78 x50x128cm

Electrical Specification:

Mains:100˜240V,50/60Hz

Power consumption: ≤50W

Optional:

Anesthesia Ventilator TH-1(A)

Anesthesia Vaporizer Eagle 2000
